Centerforce(R) brings together high-quality friction materials and patented processes to give you top-of-the-line discs.
The Centerforce(R) Dual Friction(R) Disc Series uses a single disc with patented dual friction technology by distributing pressure plate clamp force evenly over a 360-degree friction-facing on one side of the clutch disc, while the opposing side uses a segmented friction-facing to concentrate clamping pressure and increase clutch holding-capacity. These discs are made for Centerforce Dual Friction pressure plates.
The Centerforce(R) Dual Friction(R) Disc Series uses a single disc with patented dual friction technology by distributing pressure plate clamp force evenly over a 360-degree friction-facing on one side of the clutch disc, while the opposing side uses a segmented friction-facing to concentrate clamping pressure and increase clutch holding-capacity. These discs are made for Centerforce Dual Friction pressure plates.
Application Summary:
| Year | Make/Model |
|---|---|
| 1973-1975 | Buick Apollo |
| 1973 | Buick Centurion |
| 1973 | Buick Century |
| 1976-1979 | Buick Century |
| 1964-1965 | Buick LeSabre |
| 1967-1968 | Buick LeSabre |
| 1970-1973 | Buick LeSabre |
| 1973 | Buick Regal |
| 1976-1979 | Buick Regal |
| 1964-1972 | Buick Skylark |
| 1978-1979 | Buick Skylark |
| 1964-1969 | Buick Special |
| 1955-1956 | Chevrolet Bel Air |
| 1962-1969 | Chevrolet Bel Air |
| 1962-1969 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1967-1974 | Chevrolet Camaro |
| 1977-1982 | Chevrolet Camaro |
| 1966-1969 | Chevrolet Caprice |
| 1964-1973 | Chevrolet Chevelle |
| 1965-1967 | Chevrolet Chevy II |
| 1957-1968 | Chevrolet Corvette |
| 1978 | Chevrolet Corvette |
| 1964-1975 | Chevrolet El Camino |
| 1978-1981 | Chevrolet El Camino |
| 1962-1969 | Chevrolet Impala |
| 1975 | Chevrolet Malibu |
| 1978-1981 | Chevrolet Malibu |
| 1971-1975 | Chevrolet Monte Carlo |
| 1978-1979 | Chevrolet Monte Carlo |
| 1981 | Chevrolet Monte Carlo |
| 1969-1979 | Chevrolet Nova |
| 1978-1981 | GMC Caballero |
| 1971-1977 | GMC Sprint |
| 1965-1967 | Oldsmobile Cutlass |
| 1979-1981 | Oldsmobile Cutlass |
| 1968-1972 | Oldsmobile Delta 88 |
| 1979 | Oldsmobile Omega |
| 1965-1972 | Oldsmobile Vista Cruiser |
| 1963-1966 | Pontiac Bonneville |
| 1970-1971 | Pontiac Bonneville |
| 1963-1966 | Pontiac Catalina |
| 1970-1971 | Pontiac Catalina |
| 1967-1970 | Pontiac Executive |
| 1967-1982 | Pontiac Firebird |
| 1963-1966 | Pontiac Grand Prix |
| 1965-1971 | Pontiac GTO |
| 1964-1971 | Pontiac LeMans |
| 1975-1977 | Pontiac LeMans |
| 1979 | Pontiac LeMans |
| 1979 | Pontiac Phoenix |
| 1964-1970 | Pontiac Tempest |
| 1971-1977 | Pontiac Ventura |
| Attributes | |
| ASIN | B005HDM9BI |
| Attribute Data | 2 |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter | 10.4, 10.4, 264.2 |
| Clutch Disc Type | Sprung |
| Country of Origin (Primary) | TH |
| Disc Material | Organic/Carbon composite, Organic/Carbon composite, Organic/Carbon Composite |
| Disc Type | Full face/Segmented face, Full face/Segmented face, Full face/Segmented face |
| Disc Type Sprung Solid | Sprung, Sprung, Sprung |
| Emission Code | Legal US |
| Harmonized Tariff Code (Schedule B) | 8708935000 |
| Hazardous Material Code | N |
| Includes | Disc |
| Input Shaft Diameter | 1-1/8, 1-1/8, 1-1/8 |
| Input Spline Quantity | 10, 10, 10 |
| Inside Diameter of Friction Surface | 6.490, 6.490, 164.8, 6.490 |
| Life Cycle Status Code | Available to Order |
| Made In The USA | Assembled, Assembled |
| Material | Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction |
| NAFTA Preference Criterion Code | B |
| Out of Package Weight | 4.34, 4.34 |
| Outside Diameter of Friction Surface (Standard) | 10.4 |
| SDR Required Flag | N |
| Spline Diameter and Tooth Count | 1-1/8"-10 |
| Standard Pack | 1 |
| Warranty Time | 12 |
| GTIN | 00788442027617 |
