Fits 2004-2008 Ford F-150 trucks, 4.6L, 5.4L engine, 2/4 Wheel drive, all Wheelbases. - Moderate sound
The Flowmaster® Flow FX Cat-back exhaust system is designed for 2004-2008 Ford F-150 trucks with 4.6L and 5.4L engines. This bolt-on system is manufactured using durable 409 stainless steel throughout, and features a 3.00-inch inlet pipe leading to a single inlet/dual outlet Flow FX® straight-through muffler for a deep, moderately aggressive sound and maximum performance. The dual 2.50-inch mandrel-bent tailpipes are custom routed to clear the factory spare tire and tow hitch without any clearance issues and exit out the sides behind the rear tires, which is ideal when towing so you don't blow exhaust fumes on your boat, vehicle or trailer. The system is then finished off with a pair of large 4.50-inch black ceramic coated stainless steel tips, giving your F-150 an aggressive look to go with the sound of the Flow FX performance muffler. This system utilizes the factory hanger locations and includes detailed instructions and all necessary hardware for an easy at home installation. Notes: Fits all 2/4 wheel drive models and all wheelbases.
- Large 4.5-inch Black Ceramic Coated Stainless Steel Tips
- Flow FX "Straight-through" Performance Mufflers
- Deep Powerful Tone Exterior Sound
- Includes All Necessary Hardware
- Full Stainless Steel Construction
- Clears the Factory Spare Tire
- Lifetime Limited Warranty
- Easy at Home Installation
Information:
2004-2008 Ford F-150 trucks, 4.6L, 5.4L engine, 2/4 Wheel drive, all Wheelbases.
Application Summary:
| Year |
Make/Model |
| 2004-2008 |
Ford F-150 |
| Attributes |
| Brand |
Flowmaster, Flowmaster |
| C.A.R.B EO # |
No |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB (California) Compliant |
Yes |
| CARB EO |
No |
| Catalytic Converter Included |
No |
| Catalytic Converter Quantity |
Not Included |
| Category |
Exhaust, Exhaust |
| Clamping Type |
Flat Band, Flat Band |
| Clamps Included |
Yes, Yes |
| Country of Origin (Primary) |
US |
| Emission Code |
5, 5 |
| Exhaust Series |
FlowFX, FlowFX |
| Exhaust System Kit Type |
Cat-Back |
| Exhaust Tip Diameter |
4.50, 4.50 |
| Exhaust Tip Finish |
Black Ceramic Coating, Black Ceramic Coating |
| Exhaust Tip Length |
11.00 |
| Exhaust Tip Material |
304 Stainless Steel, 304 Stainless Steel |
| Exhaust Tip Quantity |
2, 2 |
| Exhaust Type |
Cat-Back |
| Exit Position |
Single Side, Dual Side Exit |
| Finish |
Natural, Natural |
| Gasket Or Seal Included |
No, No |
| Grade Type |
Performance, Performance |
| Hangers Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Inside Diameter |
3.000 in. |
| Inlet Type |
Clamp-On, Clamp-On |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2-1/2 |
| Material |
Stainless Steel, 409 Stainless Steel |
| Mount Type |
Uses Factory Hanger, Uses Factory Hanger |
| Mounting Bracket Included |
Yes, Yes |
| Muffler Body Height |
4.00 |
| Muffler Body Length |
18.00, 18.00 |
| Muffler Body Material |
409 Stainless Steel, 409 Stainless Steel |
| Muffler Body Shape |
Oval, Oval |
| Muffler Body Width |
9.00 |
| Muffler Flanged Inlet |
No, No |
| Muffler Flanged Outlet |
No, No |
| Muffler Included |
Yes |
| Muffler Inlet Diameter |
3.00 |
| Muffler Inlet Diameter (in) |
3 |
| Muffler Inlet Inside Diameter |
3.00, 3.00 |
| Muffler Inlet Location |
Centered, Center |
| Muffler Inlet Outside Diameter |
3.13, 3.13 |
| Muffler Outlet Diameter |
2.50, 2.50 |
| Muffler Outlet Diameter (in) |
2.5 |
| Muffler Outlet Location |
Dual Outlet, Dual |
| Muffler Outlet Quantity |
1, 1 |
| Muffler Quantity |
1, 1 |
| Muffler Type |
Absorption, Absorption |
| NAFTA Preference Criterion Code |
B |
| Part Type |
Exhaust System Kit, Exhaust System |
| Pipe Color |
Silver, Silver |
| Pipe Material |
409 Stainless Steel, Stainless Steel |
| Product Type |
Cat-Back Exhaust, Exhaust System |
| SDR Required Flag |
N |
| Series |
FlowFX Exhaust Kits |
| Single Dual |
Dual |
| Sound Level |
Moderate, Moderate |
| Spring Bolt Kit Included |
No, No |
| Sub Category |
Exhaust and Tail Pipes, Exhaust and Tail Pipes |
| Subcategory |
Cat-Back Exhaust Kits |
| System Type |
Cat-back |
| Tail Pipe Diameter |
3.000 in. |
| Tail Pipe Outlet Outside Diameter |
2.50 |
| Tail Pipe Quantity |
2, Dual |
| Tail Pipe Tapered Outlet |
No, No |
| Tip Cut |
Angle |
| Tip Diameter |
4.500 in., 4.5 |
| Tip Edge Style |
Rolled |
| Tip Finish |
Black Ceramic, Black Ceramic Coating |
| Tip Length |
11, 11.00 |
| Tip Logo |
Embossed, Embossed |
| Tip Material |
304 Stainless, 304 Stainless Steel |
| Tip Shape |
Round |
| Tip Style |
Single Wall |
| Tubing Diameter |
3.000 in., 2.50 |
| Tubing Diameter (IN) |
2.5 |
| Tubing Material |
409S Stainless Steel, 409 Stainless Steel |
| Type |
Cat-Back, Cat-Back |
| Valve Included |
No, No |
| Valve Type |
Not Applicable, Not Applicable |
| Warning |
California Proposition 65, California Proposition 65 |
| GTIN |
00700042039234 |
