Fits 1994-2001 Dodge RAM 1500 and 1994-2002 2500/3500 with 3.9L / 5.2L / 5.9L Engines, Stainless Steel, Dual Exit
This Flow FX cat-back exhaust system is designed for the 1994-2001 Dodge Ram 1500 and 1994-2002 2500/3500 models with the 3.9L, 5.2L or 5.9L engine. Features include 409 stainless steel construction for added durability and 16-gauge 2.5-inch mandrel-bent tubing for free unrestricted flow. The compact oval "straight-through" Flow FX performance muffler delivers a moderate yet deep and powerful sound while the interior sound is kept very mild. The system uses the factory hanger locations and is finished off with two 4.50-inch black ceramic-coated 304 stainless steel tips embossed with the Flowmaster name exiting on each side of the truck. The kit includes detailed instructions and all hardware necessary for a quick and easy installation you can do at home. Backed by Flowmaster's Lifetime Limited Warranty.
- This system produces a moderate rumble with minimal interior resonance
- Includes Two large 4.5-inch black ceramic coated tips exiting out each side of the truck for an aggressive look
- Flow FX “straight through” performance muffler delivers a deep performance tone and improves exhaust flow
- Increases of up to 7 HP and 7 FT/LB over the stock exhaust
- Includes complete hardware and factory styled hangers in the stock locations for an easy installation
- 2.5-inch Mandrel bent 16 gauge 409 stainless steel tubing maximizes exhaust flow and improved durability
- Lifetime Limited Warranty
Information:
Fits both 2 and 4 wheel drive, all wheelbases
Application Summary:
| Year |
Make/Model |
| 1994-2002 |
Dodge Ram 1500 |
| 1994-2002 |
Dodge Ram 2500 |
| 1994-2002 |
Dodge Ram 3500 |
| Attributes |
| Brand |
Flowmaster |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB (California) Compliant |
Yes |
| Catalytic Converter Included |
No |
| Catalytic Converter Quantity |
Not Included |
| Category |
Exhaust, Exhaust |
| Clamping Type |
Flat Band, Flat Band |
| Clamps Included |
Yes, Yes |
| Country of Origin (Primary) |
US |
| Emission Code |
5, 5 |
| Exhaust Series |
FlowFX, FlowFX |
| Exhaust System Kit Type |
Cat-Back |
| Exhaust Tip Diameter |
4.50, 4.50 |
| Exhaust Tip Finish |
Black Ceramic Coating, Black Ceramic Coating |
| Exhaust Tip Length |
11.00 |
| Exhaust Tip Material |
304 Stainless Steel, 304 Stainless Steel |
| Exhaust Tip Quantity |
2, 2 |
| Exhaust Type |
Cat-Back |
| Exit Position |
Dual, Dual Out Side |
| Finish |
Natural, Natural |
| Gasket Or Seal Included |
No, No |
| Grade Type |
Performance, Performance |
| Hangers Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Inside Diameter |
3.000 in. |
| Inlet Type |
Clamp-On, Clamp-On |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2-1/2 |
| Material |
409S Stainless Steel, 409 Stainless Steel |
| Mount Type |
Uses Factory Hangers, Uses Factory Hangers |
| Mounting Bracket Included |
Yes, Yes |
| Muffler Body Height |
4.00 |
| Muffler Body Length |
18.000 in., 18.00 |
| Muffler Body Length (in) |
18 |
| Muffler Body Material |
409 Stainless Steel, 409 Stainless Steel |
| Muffler Body Shape |
Oval, Oval |
| Muffler Body Width |
9.00 |
| Muffler Color |
Natural, Silver |
| Muffler Flanged Inlet |
No, No |
| Muffler Flanged Outlet |
No, No |
| Muffler Included |
Yes |
| Muffler Inlet Diameter |
3, 3.00 |
| Muffler Inlet Inside Diameter |
3.00, 3.00 |
| Muffler Inlet Location |
Centered, Center |
| Muffler Inlet Outside Diameter |
3.13, 3.13 |
| Muffler Material |
409S Stainless Steel, 409 Stainless Steel |
| Muffler Outlet Diameter |
2.5, 2.50 |
| Muffler Outlet Quantity |
2, 2 |
| Muffler Overall Length |
24.00, 24.00 |
| Muffler Overall Length (in) |
24 |
| Muffler Part Number |
Kit Only, Kit Only |
| Muffler Quantity |
1, 1 |
| Muffler Series |
FlowFX, FlowFX |
| Muffler Shape |
Oval |
| Muffler Type |
Absorption, Absorption |
| NAFTA Preference Criterion Code |
B |
| Part Type |
Exhaust System Kit, Exhaust System |
| Pipe Color |
Silver, Silver |
| Pipe Material |
409 Stainless Steel, 409 Stainless Steel |
| Product Type |
Exhaust System, Exhaust System |
| SDR Required Flag |
N |
| SDS Sheet Number |
N |
| Series |
FlowFX Exhaust Kits |
| Single Dual |
Dual |
| Sound Level |
Moderate, Moderate |
| Spring Bolt Kit Included |
No, No |
| Sub Category |
Exhaust and Tail Pipes, Exhaust and Tail Pipes |
| Subcategory |
Cat-Back Exhaust Kits |
| System Type |
Cat-back |
| Tail Pipe Outlet Outside Diameter |
2.50 |
| Tail Pipe Quantity |
2, Dual |
| Tail Pipe Tapered Outlet |
No, No |
| Tip Cut |
Angle |
| Tip Diameter |
4.500 in., 4.5 |
| Tip Edge Style |
Rolled |
| Tip Finish |
Black Ceramic, Black Ceramic Coating |
| Tip Length |
11, 11.00 |
| Tip Logo |
Embossed, Embossed |
| Tip Material |
304 Stainless, 304 Stainless Steel |
| Tip Quantity |
2 |
| Tip Shape |
Round |
| Tip Style |
Single Wall |
| Tubing Diameter |
2.500 in., 2.50 |
| Tubing Diameter (IN) |
2.5 |
| Tubing Material |
409S Stainless Steel, 409 Stainless Steel |
| Type |
Cat-Back, Cat-Back |
| Valve Included |
No, No |
| Valve Type |
Not Applicable, Not Applicable |
| Warning |
California Proposition 65, California Proposition 65 |
| GTIN |
00090127108895 |
