750 CFM - 4150 - Mechanical Secondaries - Shiny - Gasoline
These carburetors that are intended for use with superchargers, and have a unique capability that allows their power valves to reference the intake manifold vacuum below the supercharger. This allows the power valve to operate as it should, based off intake manifold vacuum. A power valve provides further enrichment to the main metering system under load (low vacuum) conditions. Without this external referencing, the power valve would be "reading" the supercharger vacuum, which has no bearing on the engine load.
These carburetors that are intended for use with superchargers, and have a unique capability that allows their power valves to reference the intake manifold vacuum below the supercharger. This allows the power valve to operate as it should, based off intake manifold vacuum. A power valve provides further enrichment to the main metering system under load (low vacuum) conditions. Without this external referencing, the power valve would be "reading" the supercharger vacuum, which has no bearing on the engine load.
- Tumble polished shiny finish for good looks
- Boost referenced power valve for proper enrichment under acceleration
- 100% wet-flow tested by Holley technicians to assure it arrives ready to run!
- Small block Chevrolet 1x4, 170 series blower calibration
- Manual (Cable driven, hand operated) choke for precise cold start control
- Dual accelerator pumps for addition fuel under initial acceleration
- Dual feed fuel inlets for constant high volume fuel delivery
- Mechanical Secondaries for perfect off the line launches
- 4 corner idle allows you to precisely control your idle system
- Intended for lightweight vehicles w/ manual trans or automatics with high stall & low gearing
Information:
This model of carburetor has the square bore flange bolt pattern. It can replace Holley, Edelbrock, Carter AFB, and Autolite style carburetors with 5 3/16" x 5 5/8" bolt pattern. If you have a spreadbore style intake manifold, you will need an adapter to install this carburetor. Similar to the Mr. Gasket #1932.Application Summary:
| Year | Make/Model |
|---|---|
| 1962-1973 | AC Shelby Cobra |
| 1952-1954 | Allard J2X |
| 1954 | Allard K3 |
| 1952-1954 | Allard Monte Carlo |
| 1952-1954 | Allard Safari |
| 1960-1974 | American Motors Ambassador |
| 1966-1968 | American Motors American |
| 1968-1970 | American Motors AMX |
| 1961-1962 | American Motors Classic |
| 1965-1966 | American Motors Classic |
| 1971-1974 | American Motors Hornet |
| 1968-1974 | American Motors Javelin |
| 1965-1967 | American Motors Marlin |
| 1971-1976 | American Motors Matador |
| 1969 | American Motors Rambler |
| 1961 | American Motors Rebel |
| 1967-1968 | American Motors Rebel |
| 1970 | American Motors Rebel |
| 1966 | American Motors Rogue |
| 1962-1965 | Apollo GT |
| 1965-1985 | Avanti II |
| 1987-1991 | Avanti II |
| 1992-1995 | Bentley Continental |
| 1965-1969 | Bizzarrini GT America |
| 1974 | Bricklin SV-1 |
| 1961-1963 | Bristol 407 |
| 1963-1965 | Bristol 408 |
| 1965-1967 | Bristol 409 |
| 1967-1969 | Bristol 410 |
| 1969-1974 | Bristol 411 |
| 1973-1975 | Buick Apollo |
| 1971-1973 | Buick Centurion |
| 1954-1958 | Buick Century |
| 1973-1981 | Buick Century |
| 1959-1989 | Buick Electra |
| 1959-1964 | Buick Estate Wagon |
| 1970-1983 | Buick Estate Wagon |
| 1967 | Buick Gran Sport |
| 1970-1972 | Buick GS |
| 1968-1969 | Buick GS 350 |
| 1968-1969 | Buick GS 400 |
| 1970-1972 | Buick GS 455 |
| 1959-1963 | Buick Invicta |
| 1959-1990 | Buick LeSabre |
| 1958 | Buick Limited |
| 1973-1987 | Buick Regal |
| 1963-1985 | Buick Riviera |
| 1952-1958 | Buick Roadmaster |
| 1954 | Buick Skylark |
| 1961-1972 | Buick Skylark |
| 1975-1979 | Buick Skylark |
| 1961-1969 | Buick Special |
| 1964-1972 | Buick Sportwagon |
| 1955-1958 | Buick Super |
| 1962-1970 | Buick Wildcat |
| 1987-1990 | Cadillac Brougham |
| 1965-1976 | Cadillac Calais |
| 1952-1984 | Cadillac Commercial Chassis |
| 1953-1982 | Cadillac DeVille |
| 1953-1978 | Cadillac Eldorado |
| 1981-1982 | Cadillac Eldorado |
| 1965-1982 | Cadillac Fleetwood |
| 1986 | Cadillac Fleetwood |
| 1952-1964 | Cadillac Series 60 Fleetwood |
| 1952-1964 | Cadillac Series 62 |
| 1958 | Cadillac Series 70 Fleetwood Eldorado |
| 1952-1964 | Cadillac Series 75 Fleetwood |
| 1981-1982 | Cadillac Seville |
| 1966-1974 | Checker Aerobus |
| 1969-1970 | Checker Deluxe |
| 1965-1974 | Checker Marathon |
| 1977-1979 | Checker Marathon |
| Attributes | |
| ASIN | B00062ZDN6 |
| Barrel | Four |
| Barrel Quantity | 4 |
| Barrels | 4, 4 |
| Body Color | Polished Aluminum |
| Body Finish | Polished |
| Body Material | Aluminum |
| Booster | Down Leg, Downleg |
| Booster Type | Down Leg |
| Brand | Holley, Holley |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Carburetor Material | Aluminum, Aluminum |
| Carburetor Type | 4150 |
| Carburetor Use | Performance and Race, Performance and Race |
| Category | Carburetors and Components, Carburetors and Components |
| CFM | 750, 750 |
| CFM Rating | 750 |
| Choke | Manual, Manual |
| Choke Type | Manual, Manual |
| Color | Polished Aluminum |
| Condition | New, New |
| Country of Origin (Primary) | US |
| Cubic Feet Per Minute Rating | 750, 750 |
| Emission | Without EGR |
| Emission Code | 3, 3, Off Road |
| Finish | Shiny, Shiny |
| Flange | Square Bore |
| Flange Shape | Square |
| Flange Type | Square/4150, Square/4150 |
| Fuel | Gasoline, Gasoline |
| Fuel Inlet | Dual, Dual |
| Fuel Type | Gasoline, Gasoline |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Linkage Attached | Yes, Yes |
| Marine Approved | No, No |
| Marine Use | No, No |
| Material | Zinc, Aluminium |
| Model | 4150, 4150 |
| Mounting Hole Quantity | 4, 4 |
| NAFTA Preference Criterion Code | B |
| Part Type | Carburetor, Carburetor |
| Primary Jet Diameter | 74, 74 |
| Primary Main Jet | 74, 74 |
| Primary Main Jet Size | 74, 74 |
| Primary Power Valve | 10.5, 10.5 |
| Primary Pump Nozzle Size | 28, 28 |
| Product Type | 4150 Model Carburetor, Carburetor |
| Sale Category | Carburetors and Components |
| SDR Required Flag | N |
| Secondaries | Mechanical, Mechanical |
| Secondary Main Jet | 84, 84 |
| Secondary Main Jet Size | 84, 84 |
| Secondary Pump Nozzle Size | 31, 31 |
| Secondary Type | Mechanical |
| Spacer Included | No, No |
| Supercharged Application | Yes, Yes |
| Supercharger Compatible | Yes, Yes |
| System Type | Draw Thru, Draw Thru |
| Throttle Bore | 1.688 in., 1.688 inch |
| Throttle Bore (in.) | 1.688 |
| Throttle Bore Diameter | 1.688 inch, 1.688 inch |
| Type | Automotive |
| Usage | Street/Strip |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127467190 |
