EFI Throttle Body Intake Elbow 4150 - Fits Ford Throttle Bodies
This cast EFI intake elbow allows the use of Ford throttle bodies on any intake manifold w/ the 4150 mounting flange. Slotted mounting holes & dual throttle cable mounting bracket bosses allow the elbow & throttle body to be mounted forward, sideways, or rearward. Features (4) vacuum ports, MAP sensor port, machined / port matched to 4150 gasket, and 100° throttle body angle for extra hood clearance. Includes MAP sensor port cover, gaskets, throttle cable bracket, and hardware.
This cast EFI intake elbow allows the use of Ford throttle bodies on any intake manifold w/ the 4150 mounting flange. Slotted mounting holes & dual throttle cable mounting bracket bosses allow the elbow & throttle body to be mounted forward, sideways, or rearward. Features (4) vacuum ports, MAP sensor port, machined / port matched to 4150 gasket, and 100° throttle body angle for extra hood clearance. Includes MAP sensor port cover, gaskets, throttle cable bracket, and hardware.
- Fits Ford Throttle Bodies
- 105mm Throttle Body Opening - 100° Mounting Angle
- Fits Intakes w/ 4150 Flange
- Slotted Mounting Holes Allow Forward, Sideways or Rearward Throttle Body Mounting
- LS3 Style MAP Sensor Mounting
- (4) Vacuum Ports – (1) Each 1/4” NPT & 3/8” NPT & (2) 1/8” NPT w/ Indirect Baffled Signal
- (2) Throttle Linkage Mounting Bosses
- Sand Cast w/ Satin Finish
- Overall Height 5.12”
| Attributes | |
| Brand | Holley EFI |
| California Proposition 65 | No |
| Category | Air and Fuel Delivery, Intake Manifolds |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| Color | Silver |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Emission Code | 3, 3, Off Road |
| Engine | GM LS1/LS2/LS6, GM LS1/LS2/LS6 |
| Finish | Silver, Silver |
| Flange Style | EFI |
| Fuel System Type | EFI, EFI |
| Gasket Or Seal Included | Yes |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Height | 5.12", 5.12" |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Part Type | Fuel Injection Throttle Body Adapter |
| Product Type | Intake Elbow, Intake Elbow |
| Sale Category | Air and Fuel Delivery |
| SDR Required Flag | N |
| Sub Category | Hardware, Fasteners and Fittings |
| Throttle Bore | 105mm, 105mm |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127061190 |
