EFI Throttle Body Intake Elbow 4500 - Fits GM LS Throttle Bodies
Features (4) vacuum ports, MAP sensor port, machined / port matched to 4500 gasket, and 100° throttle body angle for extra hood clearance. Includes billet MAP sensor port cover, gaskets & hardware. The port design spacing will also allow a transducer to be used if a MAP sensor is not needed. The intake flange has an o-ring groove for a positive flange seal and the o-ring is included as well.
Features (4) vacuum ports, MAP sensor port, machined / port matched to 4500 gasket, and 100° throttle body angle for extra hood clearance. Includes billet MAP sensor port cover, gaskets & hardware. The port design spacing will also allow a transducer to be used if a MAP sensor is not needed. The intake flange has an o-ring groove for a positive flange seal and the o-ring is included as well.
- Fits GM LS Throttle Bodies
- 105mm Throttle Body Opening - 100° Mounting Angle
- Fits Intakes w/ 4500 Flange- designed to use the included o-ring for sealing
- The 4500 square flange pattern allows Forward, Sideways or Rearward Throttle Body Mounting
- LS3 Style MAP Sensor Mounting
- (4) vacuum ports, MAP sensor port,
- (2) Throttle Linkage Mounting Bosses
- Machined Billet finish
- Overall Height 6.38”
| Attributes | |
| Brand | Holley EFI |
| California Proposition 65 | No |
| Category | Air and Fuel Delivery |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| Color | Silver |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Emission Code | 3, 3, Off Road |
| Engine | GM LS1/LS2/LS6, GM LS1/LS2/LS6 |
| Finish | Silver, Silver |
| Fuel System Type | EFI, EFI |
| Gasket Or Seal Included | Yes |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Height | 6.3", 6.3" |
| Life Cycle Status Code | Available to Order |
| Material | Billet Aluminum |
| NAFTA Preference Criterion Code | B |
| Part Type | Fuel Injection Throttle Body Adapter |
| Product Type | Intake Elbow, Intake Elbow |
| SDR Required Flag | N |
| Sub Category | Hardware, Fasteners and Fittings |
| Throttle Bore | 105mm, 105mm |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127062838 |
