HOLLEY SMART COIL – HIGH HORSEPOWER C-N-P V8 KIT
Do you need precision control over your ignition system? Would your combination benefit from Individual Cylinder Timing Control? Are you experiencing spark issues with your Stock Coils? Are you wanting to convert your Turbocharged Big Block Monstrosity to Coil-Near-Plug?! Problem solved, introducing the Holley EFI Big-Wire C-N-P Kit containing everything you need to upgrade your ignition system to handle 5.5+ HP per Cubic Inch
Do you need precision control over your ignition system? Would your combination benefit from Individual Cylinder Timing Control? Are you experiencing spark issues with your Stock Coils? Are you wanting to convert your Turbocharged Big Block Monstrosity to Coil-Near-Plug?! Problem solved, introducing the Holley EFI Big-Wire C-N-P Kit containing everything you need to upgrade your ignition system to handle 5.5+ HP per Cubic Inch
- “Big Wire” Sub Harness- Pre wired with 12ga Power and Grounds, for optimal performance!
- Peak Voltage – 44,000 Volts
- Peak Output – 102 Mj
- Maximum Battery Voltage 17.0 Volts
- Upgrading a Non C-N-P Main Harness requires the Holley Universal Coil-On-Plug Harness, P/N 558-307 to complete the installation!
- Contains two Terminated Sub-Harnesses, and Eight Holley Smart Coils, 3 ft. of wiring loom for a professional appearing installation!
- Sub Harness features Fully Terminated Coil Connectors, a 7 Pin Metripak Connector used on several Holley EFI C-N-P Main Harnesses, and 3 loose wires for a quick installation!
Information:
The supplied connectors and pins are "Pull to Seat " This means that you need to insert the wire through the connector from the back, crimp the pin and pull it back into the connector for assembly. Always use proper crimping tools to ensure a proper connection.| Attributes | |
| Brand | Holley EFI, Holley EFI |
| California Proposition 65 | No |
| Category | Ignition |
| Country of Origin (Primary) | US |
| Emission Code | 4, 4, Off Road |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Height | 1.86", 1.86" |
| Ignition Wire Terminal Type | HEI Style Tower, HEI Style Tower |
| Item Height | 1.860 in. |
| Life Cycle Status Code | Available to Order |
| Mounting Bolt Pattern | 74mm, 74mm |
| NAFTA Preference Criterion Code | B |
| Overall Length | 4.300 in., 4.3" |
| Overall Length (in.) | 4.300 in. |
| Part Type | Direct Ignition Coil Kit |
| Product Type | Distrutorless Ignition - DIS - smart coil, Distrutorless Ignition - DIS - smart coil |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Sub Category | Ignition Coil |
| Warning | California Proposition 65, California Proposition 65 |
| Width | 3.600 in., 3.6" |
| Width (in.) | 3.6 |
| GTIN | 00090127002544 |
