The Centerforce(R) TRIAD DS (Drive System) 8.75 Inch patented multi-disc clutch offers a smaller and lighter system for quick revving vehicles with engine torque levels from 500 to 1100 ft/lbs.
The Centerforce(R) TRIAD DS 8.75" triple disc clutch has been developed for vehicles requiring a holding capacity of 500 to 1100 ft/lbs of torque at the crank. The billet pressure plate features our patented centrifugal weight system (where applicable) for superior clamp load over stock and our patented ball bearing actuated pressure plate (where applicable) providing light pedal effort. The solid hub (possible gear noise) disc pack is equipped with Kevlar full facing friction material providing increased holding capacity. TRIAD DS clutches are equipped with a lightened billet steel flywheel providing low inertia resulting in quicker RPM's. Vehicles may experience some floater noise during operation. Components are designed, machined and assembled in the USA. TRIAD DS clutches are match balanced and ready for installation using the included ARP fasteners.
Application Summary:
| Year |
Make/Model |
| 2016-2018 |
Chevrolet Camaro |
| 2014-2019 |
Chevrolet Corvette |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov, WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
8.75, 8.75, 222, 222 |
| Counterweight Assist |
No, Yes, No |
| Country of Origin (Primary) |
US |
| Crankshaft Bolt Hole Quantity |
8, 8, 8 |
| Disc Type Sprung Solid |
Solid, Solid, Solid |
| Emission Code |
Legal US |
| Flywheel Crank Bolt Size |
MM11 x 1.50 x 23, 11mm, MM11 x 1.50 x 23 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-1/8, 1-1/8, 1-1/8 |
| Input Spline Quantity |
26, 26, 26 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Full Face Organic Friction, Cast Iron Pressure Plate / Full Face Organic Friction, Cast Iron Pressure Plate / Full Face Organic Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter |
14.096 |
| Pilot Bushing Included |
Yes, Yes |
| Replaceable Friction Surface |
N, N, N |
| Ring Gear O.D |
14.096 |
| Ring Gear O.D. |
14.105, 14.105 |
| Ring Gear OD |
14.096 |
| Ring Gear Tooth Count |
168, 168 |
| SDR Required Flag |
N |
| Tooth Quantity |
168, 168 |
| Torque Capacity |
900, 900, 900 |
| Warranty Time |
12 |
| GTIN |
00788442034769 |
