Centerforce(R) II Clutch Series utilizes our centrifugal weights and patented machining processes for superb holding power and maximum clutch life.
this combination allows superb holding power and maximum clutch life, making this clutch ideal for selected street/strip, off-road and towing applications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce II Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Application Summary:
| Year |
Make/Model |
| 2005-2019 |
Nissan Frontier |
| 2005-2015 |
Nissan Xterra |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B003V8QLJM |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Centrifugal Weights |
Without Centrifugal Weights |
| Clutch Disc Diameter |
10.4, 10.4, 260, 260 |
| Counterweight Assist |
No, N, No |
| Country of Origin (Primary) |
TH |
| Disc Material |
Organic, Organic |
| Disc Type |
Full face, Full face |
| Disc Type Sprung Solid |
Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, T.O.B., Pilot Bearing, Alignment Tool |
| Input Shaft Diameter |
1, 1 |
| Input Spline Quantity |
24, 24 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface |
260 |
| Outside Diameter of Friction Surface (Metric) |
260 |
| Outside Diameter of Friction Surface (Standard) |
10.4 |
| Pilot Bushing Included |
Yes, Yes |
| Release Bearing Included |
Yes, Yes |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
1"-24 |
| Standard Pack |
1 |
| Torque Capacity |
431, 431, 431 |
| Warranty Time |
12 |
| GTIN |
00788442026221 |
