Centerforce(R) II Clutch Series utilizes our centrifugal weights and patented machining processes for superb holding power and maximum clutch life.
this combination allows superb holding power and maximum clutch life, making this clutch ideal for selected street/strip, off-road and towing applications. Pressure plate and disc sold separately on some applications. The Torque Figures for Centerforce II Pressure Plates are based and calculated in conjunction with a Centerforce I & II Clutch Disc.
Application Summary:
| Year |
Make/Model |
| 1992-1997 |
Lexus SC300 |
| 1985-1988 |
Toyota 4Runner |
| 1992-1995 |
Toyota 4Runner |
| 1982-1985 |
Toyota Celica |
| 1984-1987 |
Toyota Cressida |
| 1985-1988 |
Toyota Pickup |
| 1992-1995 |
Toyota Pickup |
| 1986-1992 |
Toyota Supra |
| 1995-2004 |
Toyota Tacoma |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B000CISPG6 |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
9.250, 9.250, 236, 236 |
| Counterweight Assist |
YES, Y, YES |
| Country of Origin (Primary) |
CN |
| Disc Material |
Organic, Organic |
| Disc Type |
Full face, Full face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Step |
0.018, 0.018 |
| Flywheel Step Type |
STEP |
| Friction Surface Configuration |
STEP |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Alignment tool. |
| Input Shaft Diameter |
1-1/8, 1-1/8 |
| Input Spline Quantity |
21, 21 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction, Cast Iron Pressure Plate / Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface |
236 |
| Outside Diameter of Friction Surface (Metric) |
236 |
| Outside Diameter of Friction Surface (Standard) |
9-1/4 |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
1-1/8"-21 |
| Standard Pack |
1 |
| Torque Capacity |
387, 387, 387 |
| Warranty Time |
12 |
| GTIN |
00788442015614 |
