Centerforce(R) brings together high-quality friction materials and patented processes to give you top-of-the-line discs.
The Centerforce(R) Dual Friction(R) Disc Series uses a single disc with patented dual friction technology by distributing pressure plate clamp force evenly over a 360-degree friction-facing on one side of the clutch disc, while the opposing side uses a segmented friction-facing to concentrate clamping pressure and increase clutch holding-capacity. These discs are made for Centerforce Dual Friction pressure plates.
Application Summary:
| Year |
Make/Model |
| 1970-1972 |
Dodge Challenger |
| 1970-1972 |
Dodge Charger |
| 1970-1972 |
Dodge Coronet |
| 1971-1972 |
Plymouth Barracuda |
| 1972 |
Plymouth Gran Fury |
| 1970-1971 |
Plymouth GTX |
| 1970-1972 |
Plymouth Road Runner |
| Attributes |
| ASIN |
B005DJ6ZY8 |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Disc Diameter |
10.700, 10.700, 271.8 |
| Country of Origin (Primary) |
TH |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite, Organic/Carbon composite |
| Disc Type |
Full face/Segmented face, Full face/Segmented face, Full face/Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Disc |
| Input Shaft Diameter |
1-3/16, 1-3/16 |
| Input Spline Quantity |
18, 18 |
| Inside Diameter of Friction Surface |
6.490, 6.490, 164.8 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Full Face and Segmented Organic Friction, Full Face and Segmented Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
4.70, 4.70 |
| Outside Diameter of Friction Surface (Standard) |
10.4 |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
1-3/16-18 |
| Standard Pack |
1 |
| Warranty Time |
12 |
| GTIN |
00788442027686 |
