The Centerforce Dual Friction(R) Clutch Series uses patented technologies for an ultimate pressure plate and disc combination.
The Centerforce(R) Dual Friction(R) Clutch Series is a performance matched pressure plate & disc combination featuring the patented Centerforce centrifugal weight system (where applicable) and specialized machining processes to provide a performance clutch that offers exceptional street characteristics, while offering outstanding holding-capacity and durability. Furthermore, the Centerforce Dual Friction disc has an organic full facing on one side for longevity and an organic segmented facing on the other side providing increased holding capacity. Some applications have the organic segmented facings of both sides. The Dual Friction clutch is engineered for those who are looking for the ultimate in street/strip holding power and performance without sacrificing pedal effort and driver control. While the Dual Friction has been engineered primarily as a street clutch it can be used in mild competition applications.
Application Summary:
| Year |
Make/Model |
| 1970-1972 |
Dodge Challenger |
| 1970-1972 |
Dodge Charger |
| 1970-1972 |
Dodge Coronet |
| 1971-1972 |
Plymouth Barracuda |
| 1972 |
Plymouth Gran Fury |
| 1970-1971 |
Plymouth GTX |
| 1970-1972 |
Plymouth Road Runner |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| ASIN |
B006YGD8QW |
| Attribute Data |
2 |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
2, 2 |
| Clutch Disc Diameter |
10.4, 10.4, 264.2 |
| Counterweight Assist |
YES, Yes, YES |
| Country of Origin (Primary) |
CN |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite |
| Disc Type |
Segmented face, Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Deck Height |
2.175, 2.175 |
| Flywheel Step Type |
Flat, Flat, Flat |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Includes |
Pressure Plate, Disc, Alignment Tool |
| Input Shaft Diameter |
1-3/16, 1-3/16 |
| Input Spline Quantity |
18, 18 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Nodular Iron Pressure Plate / Segmented Organic Friction, Nodular Iron Pressure Plate / Segmented Organic Friction, Nodular Iron Pressure Plate / Segmented Organic Friction |
| NAFTA Preference Criterion Code |
B |
| Outside Diameter of Friction Surface (Standard) |
10.4 |
| Replaceable Friction Surface |
N |
| SDR Required Flag |
N |
| SFI 1.1 Approved |
N |
| Spline Diameter and Tooth Count |
1-3/16"-18 |
| Standard Pack |
1 |
| Torque Capacity |
638, 638, 638 |
| Warranty Time |
12 |
| GTIN |
00788442027792 |
