10" diameter torque converter with 10-1/2" bolt pattern, 2800-3200 RPM Stall
*Bolts must be 3/8-16 x 3/4 to 1 inch in length and only use Grade 8 quality.
*Bolts must be 3/8-16 x 3/4 to 1 inch in length and only use Grade 8 quality.
- 3/4 Race series converters are built, tested, and proven to support up to 650 HP
- State of the art Spray Welding process is used in select areas. Spray Welding provides clean, strong and consistent fusion while also increasing strength through hardening from higher process temperature
- Each converter is hand-built and inspected in every step of assembly to ensure top of the line quality
- All HAYS converters are internally welded compared to brazing. Testing has shown welding provides longer converter life while also enhancing consistency
- Heavy duty Torrington bearings are used for greater strength and durability
- Stators are chosen with high flow vents and channels to promote cooling in heat producing higher horsepower applications
- Increased horsepower and acceleration due to a weight saving, one application design. Almost all HAYS converters are built for one application to reduce weight compared to a multi-bolt pattern converter.
- 3/4 Race series converters are offered in several different stall speeds for GM, Ford, and Chrysler transmissions
- Industry leading Tech Support Team is available to provide assistance with stall speed selection
Information:
Warning: The 3/4 RACE series converters are NOT designed to be used with Nitrous Oxide or Trans-Brakes Note: HAYS recommends an external transmission cooler for all Twister 3/4 Race Converters (A minimum size of 18,000 GVW or 15,000 BTU Rating.) Note: Stall ranges will vary depending on engine set-up, weight of vehicle, and gear ratio (Please see converter selector in tech resources for more info) *Bolts must be 3/8-16 x 3/4 to 1 inch in length and only use Grade 8 quality.Application Summary:
| Year | Make/Model |
|---|---|
| 1966-1977 | Ford Bronco |
| 1975 | Ford Courier |
| 1965-1972 | Ford Custom |
| 1973-1977 | Ford Custom 500 |
| 1969-1977 | Ford E-100 Econoline |
| 1975-1977 | Ford E-100 Econoline Club Wagon |
| 1976-1977 | Ford E-150 Econoline |
| 1976-1977 | Ford E-150 Econoline Club Wagon |
| 1975-1976 | Ford Elite |
| 1964-1978 | Ford F-100 |
| 1980-1981 | Ford F-100 |
| 1977-1978 | Ford F-150 |
| 1964-1974 | Ford F-250 |
| 1977 | Ford F-250 |
| 1964-1974 | Ford F-350 |
| 1977 | Ford F-350 |
| 1965-1969 | Ford Fairlane |
| 1978-1981 | Ford Fairmont |
| 1964-1970 | Ford Falcon |
| 1964-1967 | Ford Galaxie |
| 1968-1974 | Ford Galaxie 500 |
| 1975-1976 | Ford Gran Torino |
| 1975-1981 | Ford Granada |
| 1966-1980 | Ford LTD |
| 1977-1979 | Ford LTD II |
| 1970-1977 | Ford Maverick |
| 1964-1973 | Ford Mustang |
| 1979-1984 | Ford Mustang |
| 1974-1978 | Ford Mustang II |
| 1964-1967 | Ford P-100 |
| 1964-1974 | Ford P-350 |
| 1971-1980 | Ford Pinto |
| 1964-1971 | Ford Ranchero |
| 1975-1979 | Ford Ranchero |
| 1977-1981 | Ford Thunderbird |
| 1968-1976 | Ford Torino |
| 1977-1980 | Lincoln Versailles |
| 1975-1980 | Mercury Bobcat |
| 1972-1977 | Mercury Capri |
| 1979-1981 | Mercury Capri |
| 1964-1969 | Mercury Comet |
| 1971-1977 | Mercury Comet |
| 1967-1973 | Mercury Cougar |
| 1975-1981 | Mercury Cougar |
| 1964-1971 | Mercury Cyclone |
| 1980 | Mercury Grand Marquis |
| 1971-1974 | Mercury Marquis |
| 1980 | Mercury Marquis |
| 1975-1980 | Mercury Monarch |
| 1968 | Mercury Montclair |
| 1968-1976 | Mercury Montego |
| 1972-1974 | Mercury Monterey |
| 1978-1981 | Mercury Zephyr |
| Attributes | |
| Anti Balloon Plate | No |
| Anti-Balloon Plate | No, No |
| Balanced | Yes, Yes |
| Bolt Circle | 10-1/2", 10-1/2" |
| Bolt Circle Diameter | 10.500 in. |
| Bolt Circle Diameter (in.) | 10.50 in. |
| Bolt size | 3/8-16 x 1, 3/8-16 x 3/4 |
| Brand | Hays, Hays |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Transmission |
| Country of Origin (Primary) | US |
| Crank Pilot Diameter | 1.375 in., 1.375" |
| Diameter | 10", 10" |
| Diameter (in.) | 10.000 in. |
| Emission Code | 3, 5 |
| Harmonized Tariff Code (Schedule B) | 8483401000 |
| Hazardous Material Code | N |
| Input Shaft Spline Quantity | 24 |
| Input Spline | 24, 24 |
| Life Cycle Status Code | Available to Order |
| Lock Up Type | No |
| Lock Up/Overdrive | No, No |
| NAFTA Preference Criterion Code | B |
| Part Type | Automatic Transmission Torque Converter |
| Product Type | Torque Converters, Automatic Transmission Torque Converter |
| SDR Required Flag | N |
| Series | 3/4 Race, 3/4 Race |
| Stall | 2800-3200, 2800-3200 |
| Stall Speed (RPM) | 2800-3200 |
| Sub Category | Transmission Hard Parts |
| Thread Size (in) | 3/8 x 16, 3/8 x 16 |
| Trans Model | Ford- C- 4 (Auto) 3 Speed |
| Trans Year | 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981 |
| Transmission | C4 Case-Filled, Category |
| Transmission Model | C4 Case-Filled |
| Use with Power Adder | No, No |
| Use with Trans-Brake | No, No |
| Warning | California Proposition 65, California Proposition 65 |
| GTIN | 00090127017463 |
